    Torque Sensors

    Transcell torque sensor load cells are advanced designed and applicable for applications across industries including measurement, manufacture, automotive, medical, and more.

    TFF-325

    Features:

    • Torque sensor load cell
    • Aluminum construction
    • Easy to install
    • Suitable for robotics and force measurements
    • Capacity: 20in-oz, 50in-oz, 12in-Ib, 50in-Ib, 100in-Ib
    Specification:
    Rated Output:  2.0mV/V Safe Temp. Range: -50ºC to + 93ºC
    Nonlinearity: ±0.2% of rated output Temp. Compensated: 15ºC to + 72ºC
    Hysteresis: ±0.2% of rated output Input Impedance: 1000 ohm
    Repeatability: ±0.05% of rated output Output Impedance: 1000 ohm
    Temp. effect on output: ≤0.0036% of applied output/ºC Rated Excitation: 10V DC/AC
    Temp. effect on zero: ≤0.0036% of rated output/ºC Maximum Excitation: 20V DC/AC
    Safe Overload: 150% of RO Wire Type: 4 Conductor, Teflon Cable
    Wire Length: 6 in Wire Specification: 29AWG
